						● Low noise ,low energy consumption ,Every day only 2KWh.
● Small body ,suitable for narrow space.
● Sealed batteries free of maintenance, safe operation and no pollution.
● Stepless speed control system, easy to operate.
● Automatic lifting limit, safety energy saving.
● Emergency reversing device and Emergency brake switch.
● HELI controller , Multiple automatic protection.
| Model | unit | CBD15 |
| Configuration number | 610 | |
| Power unit | Battery | |
| Operator type | Pedestrian | |
| Rated Capacity | kg | 1500 |
| Load Center | mm | 600 |
| Max. Lifting height | mm | 120 |
| Overall length | mm | 1630 |
| Overall width | mm | 724 |
| Overall height(with handle) | mm | 1220 |
| Drive motor | KW | DC0.63 |
| Lift motor | KW | DC0.8 |
| Controller | HELI (Options CURTIS) | |
| Battery (voltage/capacity) | V/Ah | 24/70 |
