						Configuration and Performance
● Electronic power steering system, light and low noise.
● AC Driving system, No carbon brush, maintenance free.
● USA CURTIS driving controller.
● Electromagnetic, regenerative braking system.
● Automatic lifting limit, safety, energy saving.
Safety
● Curve automatic deceleration devices, more safe.
● Stepless speed control system, safe and quiet.
● Controller with Multiple automatic protection.
● Emergency reversing device and Emergency brake switch.
| Model | unit | CBD20 | CBD20 |
| Configuration number | 150 | 180 | |
| Power unit | Battery | Battery | |
| Operator type | Pedestrian | Pedestrian | |
| Rated Capacity | kg | 2000 | 2000 |
| Load Center | mm | 600 | 600 |
| Max .Lifting height | mm | 110 | 115 |
| Overall length | mm | 1750 | 1650 |
| Overall width | mm | 720 | 725 |
| Overall height (with handle) | mm | 1385 | 1380 |
| Drive motor | KW | AC1.5 | AC0.93 |
| Lift motor | KW | DC1.2 | DC1.2 |
| Steering motor | KW | DC0.15 | / |
| Controller | CURTIS | ZAPI AC0 | |
| Battery (voltage/capacity) | V/Ah | 24/210 | 24/210 |
